MIL-DTL-19264C (OS)
Workmanship. The propellant shall be manufactured using good workmanship and shall be a
3.10
product free from foreign material. It shall be uniform in quality and manufactured in a manner to assure
compliance with requirements of this specification when examined in accordance with 4.6.3.
4. VERIFICATION
4.1 Classification of inspections. The inspection requirements specified herein are classified as follows.
a. First article inspection (see 4.3).
b. Quality conformance inspection (see 4.4).
Inspection conditions. Prior to the first article, all test activities identified in the contract shall
4.2
submit a description of the proposed procedures and equipment to be used to perform the examination and
test to the technical activity and the propelling charge design agent for review.
First article inspection. First article inspection shall be performed by the contractor, after award
4.3
of contract and prior to production, at a location acceptable to the Government. First article inspection
shall be performed on sample units which have been produced with equipment and procedures normally
used in production. First article approval is valid only on the contract under which it is granted, unless
extended by the Government to other contracts. The first article sample is intended to provide necessary
information to establish the propellant granulation needed to meet the required ballistic performance
parameters.
4.3.1 Submission. The contractor shall select three propellant granulations which, from experience,
are expected to bracket the requirements of this specification. The contractor shall submit a first article
sample as designated by the contracting officer for evaluation in accordance with 4.4.2; it shall consist of
three pilot lots of a maximum of 1,000 pounds mass each, representing the three candidate granulations.
4.3.2 Inspections to be performed. Each of the granulations comprising the first article sample and
submitted in accordance with 4.4.1 shall be tested by the Government. First article inspection shall
consist of the tests specified in Table II.
TABLE II. First article quality conformance tests.
Characteristic
Requirement
Test Method
Composition
3.2
4.6.1
Grain Form and Dimensions
3.3
4.6.2, 4.6.3
Integrity
3.4
4.6.3
Glaze
3.5
4.6.3
Stability
3.6
4.6.4
Packing Depth
3.7
4.6.5
Velocity and Pressure
3.8
4.6.6
Workmanship
3.10
4.6.3
4.3.3 Authorization. Government engineering and quality assurance personnel and the contractor
shall review the pilot lot test data and shall select a granulation size which best fits the requirements of
this specification. The technical agency shall notify the contracting officer of the selected granulation.
The contractor shall request approval from the contracting officer to produce the selected granulation. If
none of the pilot lots submitted meets the requirements of this specification, a new first article sample
4
