MIL-DTL-14970D
addition, the following data requirements should be
considered when this specification is applied on a contract,
per the Contract Data Requirements List, DD Form 1423:
Reference
DID Number
DID Title
6.4.4
DI-PACK-81059
POP Test Report
6.4 Acceptable packaging requirements. The
following packing and marking requirements have been used
for packaging Composition A-5, and are found to be
acceptable to the Government. These requirements should be
included in the contract or order for the procurement of
Composition A-5 because Composition A-5 is a hazardous
energetic material. (Caution: If the following paragraphs
are to be incorporated in a contract, they must be modified,
using standard contract language, to make them compulsory
requirements.)
6.4.1
Preservation and packaging.
6.4.1.1 Packing Level A. The Composition A-5 should
be packed in accordance with Dwg. 7548644.
6.4.1.2 Packing Level B. The Composition A-5 should
be packed in accordance with Dwg. 7548645 or Dwg. 12972281.
6.4.1.2.1 Fiberboard Carton, Dwg. 7548645. When
assembling the body or cover, the flap edges should not be
more than 1/8 inch above or below the edge of the part.
Delamination of the fiberboard which may occur where
diagonal scores meet the edge of the part will be
acceptable, provided the width of the delamination does not
exceed one inch.
6.4.1.2.2 Adhesion of glued carton joints. Each glued
joint should meet the requirements for fiber failure as
given on Dwg. 7548645 when determined as specified in 4.6.9.
6.4.2
Marking. The marking should be in accordance
with Dwg. 7548644, Dwg. 7548645 and Dwg. 12972281.
6.4.3 Performance oriented packaging (POP). The
exterior packs cited above should meet all of the POP test
requirements in accordance with the Code of Federal
Regulations, Title 49 (49 CFR), including testing, and
retesting as specified in paragraph 178.601 (e) of 49 CFR.
A POP test report should be generated in accordance with DI-
PACK-81059 following the tests. POP testing may be waived
if an acceptable non-government analogy can be made IAW 49
CFR to another pack which has successfully completed the
testing. This analogy must also be documented IAW DI-PACK-
81059. When completed, either the contractor generated POP
24
